Sieno magnetic contactors SGMC-85

  • Rated impulse withstand: 6kV
  • Rated operating current (380V AC3): 9 to 95A, including SGMC-09, SGMC-12, SGMC-18, SGMC-22, SGMC-32, SGMC-40, SGMC-50, SGMC-65, SGMC-75, SGMC-85.
  • Frequency: 50 or 60Hz
  • Complies with IEC60947-1-standard
  • Product description: Sieno magnetic contactors SGMC-85
  • INQUIRY

Sieno magnetic contactors  SGMC-85

Sieno magnetic contactors  SGMC-85 is suitable for using in the circuits up to the rated voltage 660V AC 50Hz or 60Hz, rated current up to 95A, for making, breaking, frequently starting & controlling the AC motor. Combined with the auxiliary contact block, delay timer & machine-interlocking device etc, it becomes the delay contactor, mechanical interlocking contactor, star-delta starter. With the thermal overload relay, it is combined into the electromagnetic starter. The Contactor is produced according to IEC60947-4.Rated insulation voltage: 690V

Rated impulse withstand: 6kV
Rated operating current (380V AC3): 9 to 95A, including SGMC-09, SGMC-12, SGMC-18,  SGMC-22, SGMC-32, SGMC-40, SGMC-50, SGMC-65, SGMC-75, SGMC-85.
Frequency: 50 or 60Hz
Protection degree: IP2X
Ambient air temperature: -60 to +80° C

Complies with IEC60947-1-standard


Sieno magnetic contactors  SGMC-150

Technical Data:


Type AC1 duty AC3 duty Life time
(x 104)
Aux. contact
200~240V 380~440V 500~550V 690V Electrical Mechanical
SGMC-9 20A 2.5kW 11A 5kW 9A 4kW 7A 4kW 5A 250 2500 1NO1NC
SGMC-12 20A 3.5kW 13A 5.5kW 12A 7.5kW 12A 7.5kW 9A 250 2500
SGMC-18 25A 4.5kW 18A 7.5kW 18A 7.5kW 13A 7.5kW 9A 250 2500
SGMC-22 32A 5.5kW 22A 11kW 22A 15kW 22A 15kW 18A 250 2500
SGMC-32 50A 7.5kW 32A 15kW 32A 18.5kW 28A 18.5kW 21A 200 1500 2NO2NC
SGMC-40 60A 11kW 40A 18.5kW 40A 22kW 32A 22kW 25A 200 1500
SGMC-50 80A 15kW 55A 22kW 50A 30kW 43A 30kW 33A 200 1000
SGMC-65 100A 18kW 65A 30kW 65A 37kW 60A 37kW 47A 200 1000
SGMC-75 110A 22kW 75A 37kW 75A 45kW 64A 45kW 47A 200 1000
SGMC-85 135A 25kW 85A 45kW 85A 45kW 75A 45kW 52A 200 1000
