Sieno LTA204 Signal Tower (Φ40)

LTA-204 Tower warning light
Model explain:

Description

1.Application:industrial safety equipment,maintenance of machine status

2.Make from noncombustible ABS,acidproof and dustproof

3.IP Rating:IP54

4.Different light source is available and adjustable,led and bulb

5.Integral alarm with adjustable volume up to 90db

Technical parameters

Legend
Model	LTA204-1	LTA204-2	LTA204-3	LTA204-4
Function	T-steady burn,W-flashing	T-steady burn,W-flashing	T-steady burn,W-flashing	T-steady burn,W-flashing
Light Source	Inflatable bulb	Inflatable bulb	Inflatable bulb	Inflatable bulb
Lighting	Bulb T:steady burn, W:flashing	Bulb T:steady burn, W:flashing	Bulb T:steady burn, W:flashing	Bulb T:steady burn, W:flashing
Power	3W	6W	9W	12W
Mounting	Multifuntional installation	Multifuntional installation	Multifuntional installation	Multifuntional installation
Sound	J:With Buzzer	J:With Buzzer	J:With Buzzer	J:With Buzzer
Play Sound	1 2 3	1 2 3	1 2 3	1 2 3
Voltage	DC12V DC24V	DC12V DC24V	DC12V DC24V	DC12V DC24V
Segments Num.	1 Segments	2 Segments	3 Segments	4 Segments
Color

Model	Sections	Function	Voltage	Power	Color
LTA204	1	T (Normally on)	DC12V	3W	Red
		W (Flash)	DC24V
LTA204	2	T (Normally on)	DC12V	6W	Red
		W (Flash)	DC24V		Green
LTA204	3	T (Normally on)	DC12V	9W	Red
		W (Flash)	DC24V		Yellow
					Green
LTA204	4	T (Normally on)	DC12V	12W	Red
					Yellow
		W (Flash)	DC24V		Green
					Blue

Overall dimensions
