Sieno HLG-120W Full function adjustable waterproof power supply

Features:

Universal AC input
BUilt-in power factor correction
Protections：short circuit/over load/over voltage/over temp

Cooling by free air convection

OCP point adjustable through output cable or internal potentiometer

IP67/65 design for indoor or outdoor installations
Suitble for LED lighting and moving sign applications
3Year warranty

Technical data:

Model		HLG-120-12	HLG-120-20	HLG-120-24	HLG-120-36	HLG-120-48
output	DC voltage	12V	20V	24V	36V	48V
	Constant current region	6~12V	10~20V	12~24V	18~36V	24~48V
	Rated current	10A	6A	5A	3.4A	2.5A
	Rated power	120W	120W	120W	122.4W	120W
	Ripple&noise	150mvp-p	150mvp-p	150mvp-p	200mvp-p	200mvp-p
	Voltage ADJ range	10.8~13.5V	17~22V	22~27V	33~40V	43~53V
	Current ADJ range	Can be adjusted by internal potentiometer or through output cable
		5~10A	3~6A	2.5~5A	1.7~3.4A	1.2~2.5A
input	Voltage range	90~264VAC,47~63HZ ,127~370VDC
	AC current	1.4A/115VAC,0.6A/230VAC
	Power factor	PF>0.95/230VAC,PF>0.98/115VAC Start overload protection
	efficiency	90%	93%	93%	93%	93%
	Inrush current	Cold start current 35A/115VAC,75A/230VAC
	Leakage current	< 0.75mA/240VAC
protection	Over current	95%~108%
		protection type :Constant current limiting ,auto-recovery after fault condition is removed
	Short circuit	Hiccup mode,recovers automatically after fault condition is remove
	Over voltage	14~17V	23~27V	28~34V	41~46V	54~60V
		protection type:Shut down o/p voltage re-power on to recover
	Over temperature	100℃±10℃(RTH2)
		protection type:Shut down o/p voltage re-power on to recover
environment	Working temp,humidity	-20℃~+60℃,20%~90%RH
	Storagetemp,humidity	-40℃~+85℃,10%~95%RH non-condensing
	Withstand vibration	10~500HZ,2G 10min/1cycle,period for 60 minutes,each axes
safety	Withstand voltage	I/P-O/P:3KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC
	Isolated resistance	I/P-O/P,I/P-FG,O/P-FG:100M ohms/500VDC
Fitstandard	Safety standard	Fit UL1310 CLASS2,TUV EN61347-1,EN61347-2-13, IP65approved
	EMC standard	Fit EN55015,EN61000-3-2 ClassC(>60%load):EN61000-3-3
others	Dimension	2236939mm (LWH)
	Weight/packing	1kg/20pcs/21kg/0.03m³/1.07CUFT
note	1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature.
	2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
	3. Tolerance : includes set up tolerance, line regulation and load regulation.
